6 | Patent Gear box |  | The bearings arranged near to the double screw |
Strong torque to support the screw woking |
Up cover can be open for reparing with easy |
Reducer and distributed gear box as one body |
Double circulating cooling system ensure low Temp |
All parts are standard, warranty 36 month for free. |
7 | Dosing feeder |  | Twin screws can be longer size |
Steep hopper inlarge sizes |
Esnure FIFO,(First in/First out) No Retained material |
ABB inverter in 1.5kw |
8 | Vacuum system |  | Vacuum pump power 2.2kw bigger to get good quaulity |
Steel pipe and stack tank makes easy to clean |
Ceang the system Non stop machine |
Press device on venting gate is for option. |
9 | Electrical Control system |
| Siemens PLC+ HYPET Soft Ware system |
Operating parameters can be freely defined and stored |
With speed synchronous closed-loop control and self-learning function |
Intelligent management function: power consumption, product counting, formula and process selection |
Alarm system: |
Main motor overload /Temperature over or low / Fault problem display |
Brands of electrical components: Siemens, Schneider, Delta ABB, RKC, Fuji, etc |
The all wiring is connected by socket, which is convenient for disassembly |
The core of thermocouples are imported from Europe |
All wires equipped according to safety requirements |
The electric cabinet is with 8 ventilation fans, and the air conditioner is for option |
It can work by remote debugging, diagnosis and maintenance |
